URBAN X

Frame	4130 Double Butted CrMo Tubing and Carrier Bosses, Forged Disc Mount, Internal Cables
Rear Shock	n/a
Fork	Hi-Tensile Unicrown Straight Blade, 1-1/4″ Tapered
Headset	Threadless 1-1/8”, Zero Stack
Rims	Weinmann Aluminum U28, Disc Double Wall, 27.5x32H
Hubs, Front	KT Aluminum Disc, QR w/Rubber Seal
Hubs, Rear	KT Aluminum Disc, QR w/Rubber Seal, Cassette
Tires	WTB Byway, 27.5 x 47 mm
Spokes	14G Stainless Black, 32×32
Derailleur, Front	Shimano FD-TY710, 28.6mm
Derailleur, Rear	Shimano Altus, M310
Shifters	Microshift TS71Z, 3×8
Chain	KMC Z8.3
Crankset	Shimano FC-TY301, 48/38/28T w/Chainguard, S-M:170, 175
BB	Cartridge Bearing
Cassette	Shimano CS-HG318, 11-34T, 8-Speed
Pedals	Wellgo Full Aluminum w/DU Bearing
Seatpost	Aluminum Micro-Adjust, 27.2mm
Saddle	KHS Ultra Comfort, Soft Shell
Handlebar	Aluminum Trekking, 630mm, 31.8mm
Stem	KHS Aluminum Threadless, 25D, 4-bolt, S: 80mm, M-L:90mm, XL: 100mm
Grips	Q2 Ergo Lock-On, Dual Density
Brake Levers	Bengal Aries 3
Brakes	Bengal Aries 3,Hydraulic Disc, 160mm Wave 12 Rotors
Color	Matte Black
Frame Size	S/15.5, M/18, L/20.5, XL/23
Extras	Kickstand, Fenders, Aluminum Rear Carrier

Frame	4130 Double Butted CrMo Tubing and Carrier Bosses, Forged Disc Mount, Internal cables
Rear Shock	n/a
Fork	Hi-Tensile Unicrown, Straight Blade
Headset	Threadless 1-1/8”, Zero Stack
Rims	Weinmann XTB26, 700x32H, Double Wall w/CNC Side Wall
Hubs, Front	KK Aluminum, QR, w/Rubber Seal
Hubs, Rear	KK Aluminum, QR, w/Rubber Seal, Cassette
Tires	Kenda Keen, 700 x 35c w/K-Shield
Spokes	14G Stainless Black, 32×32
Derailleur, Front	Shimano, FD-TY710, 28.6mm
Derailleur, Rear	Shimano Altus, M310
Shifters	Microshift TS71 Triggers, 3×8
Chain	KMC Z8.3
Crankset	Shimano FC-TY301, 48/38/28T w/Chainguard, S-M:170, L-XXL:175
BB	Cartridge Bearing
Cassette	Shimano CS-HG31-8, 11-34T, 8-Speed
Pedals	Wellgo Platform w/Non-slip Tread, DU Bearings
Seatpost	Aluminum Micro-Adjust, 27.2mm
Saddle	KHS Ultra Comfort, Soft Shell
Handlebar	Aluminum Trekking, 630mm, 31.8mm
Stem	KHS Aluminum Threadless, 25D, 4-bolt, S:80mm, M-L:90mm, XL:100mm, XXL: 110mm
Grips	Q2 Ergo Lock-On, Dual Density
Brake Levers	Promax Aluminum Linear Pull Trekking, 3 Finger
Brakes	Promax Aluminum Linear Pull, w/ABS System Click for more information about BrakeSafe
Color	Black, Dark Silver; Ladies: Black, Wintergreen
Frame Size	S/15.5, M/18, L/20.5, XL/23, XXL/25; Ladies: S/15.5L, M/17L

Frame	4130 Double Butted CrMo Tubing and Carrier Bosses, Forged Disc Mount, Internal cables
Rear Shock	n/a
Fork	Hi-Tensile Unicrown, Disc, Post mount, Straight Blade
Headset	Threadless 1-1/8”, Zero Stack
Rims	Weinmann U26 Disc, 700x32H, Double Wall
Hubs, Front	KK Aluminum Disc QR23 w/Rubber Seal
Hubs, Rear	KK Aluminum Disc QR23 w/Rubber Seal, Cassette
Tires	Kenda Keen, 700 x 35c w/K-Shield
Spokes	14G Stainless Black, 32×32
Derailleur, Front	Shimano, FD-TY710, 28.6mm
Derailleur, Rear	Shimano Altus, M310
Shifters	Microshift TS71 Triggers, 3×8
Chain	KMC Z8.3
Crankset	Shimano FC-TY301, 48/38/28T w/Chainguard, S-M:170, L-XXL:175
BB	Cartridge Bearing
Cassette	Shimano CS-HG31-8, 11-34T, 8-Speed
Pedals	Wellgo Platform w/Non-slip Tread, DU Bearings
Seatpost	Aluminum Micro-Adjust, 27.2mm
Saddle	KHS Ultra Comfort, Soft Shell
Handlebar	Aluminum Trekking, 630mm, 31.8mm
Stem	KHS Aluminum Threadless, 25D, 4-bolt, S:80mm, M-L:90mm, XL:100mm, XXL: 110mm
Grips	Q2 Ergo Lock-On, Dual Density
Brake Levers	Promax Aluminum Linear Pull Trekking, 3 Finger
Brakes	Bengal Cable Disc, MB606, 160mm Wave 12 Rotors, w/ABS System Click for more information about BrakeSafe
Color	Midnight Blue; Ladies: Pow Green
Frame Size	S/15.5, M/18, L/20.5, XL/23, XXL/25; Ladies: S/15.5L, M/17L

Frame	Reynolds 520 DB CrMo Tubing w/Carrier Bosses, Internal Cables
Rear Shock	n/a
Fork	Full CrMo Unicrown, Low-rider and Fender Bosses, Straight Blade
Headset	Threadless 1-1/8”, Zero Stack
Rims	Weinmann XTB26, 700x32H, Double Wall w/CNC Side Wall
Hubs, Front	KK Aluminum, QR, w/Rubber Seal
Hubs, Rear	KK Aluminum, QR, w/Rubber Seal, Cassette
Tires	Kenda Kwick Journey, 700 x 35c w/K-Shield Anti-Puncture, 60TPI
Spokes	14G Stainless Black, 32×32
Derailleur, Front	MicroShift FD-T392B, 28.6mm
Derailleur, Rear	Shimano Alivio, M3100
Shifters	Shimano Alivio, M3100, 2×9 Triggers
Chain	KMC X9 w/MissingLink
Crankset	FSA Tempo, 48/32T, S:170, M-L: 172.5, XL-XXL: 175
BB	FSA Cartridge Bearing
Cassette	Shimano CS-HG200-9, 11-36T, 9-Speed
Pedals	Wellgo Full Aluminum w/Non-Slip Tread, DU Bearings
Seatpost	Aluminum Micro-Adjust, 27.2mm
Saddle	KHS Ultra Comfort Plus, Soft Shell w/Memory Foam
Handlebar	Aluminum Trekking, 630mm, 31.8mm
Stem	KHS Aluminum Threadless, 25 Degree, 4-bolt, S:80mm, M-L:90mm, XL:100mm
Grips	Q2 Ergo Lock-On, Dual Density
Brake Levers	Promax Aluminum Forged Trekking, Knee Saver
Brakes	Tektro 855AL, Aluminum Linear Pull, Long Reach, w/ABS System Click for more information about BrakeSafe
Color	Rust, Black; Ladies: County Blue
Frame Size	S/15.5, M/18, L/20.5, XL/23, XXL/25 Ladies: S/15.5L

Frame	TIG-Welded Hi-Tensile Steel, Internal Cables
Rear Shock	n/a
Fork	Hi-Tensile Unicrown Straight Blades
Headset	1-1/8” Threaded, Zero Stack w/Aluminum Conical Top Cap
Rims	Aluminum, 700c, 32H
Hubs, Front	KT Steel, QR
Hubs, Rear	KT Steel, Nutted
Tires	Kenda Khan, 700 x 38c, Skin Wall w/Anti-Puncture
Spokes	14G Stainless, 32×32
Derailleur, Front	n/a
Derailleur, Rear	Shimano Tourney RD-TY300D
Shifters	Shimano Revo RS36
Chain	KMC Z8.3
Crankset	Aluminum Forged, 44T w/Double Chainguard, 170mm
BB	Cartridge Bearing
Freewheel	Shimano Mega Range, 14-34T, 7-Speed
Pedals	Nylon Platform
Seatpost	Aluminum Suspension, 25.4mm
Saddle	DDK Wide Comfort, Memory Foam w/Elastomer Spring
Handlebar	Aluminum, 100mm rise, 660mm
Stem	Aluminum Quill, 25 Degree
Grips	Comfort Kraton
Brake Levers	Aluminum Linear Pull
Brakes	Aluminum Linear Pull w/ABS System Click for more information about BrakeSafe
Color	Brilliant Red, Black; Low-Step: Mint, Tulip
Frame Size	S/15, M/17, L/19, XL/21, XXL/23, XXXL/25; Ladies: S/14L & M/17L Low-Step
